Magento 2.3.1: Unauthenticated Stored XSS to RCE

Simon Scannell photo

Simon Scannell

Vulnerability Researcher


  • Security
This blog post shows how the combination of a HTML sanitizer bug and a Phar Deserialization in the popular eCommerce solution Magento <=2.3.1 lead to a high severe exploit chain. This cha...


A successful attack enables an unauthenticated adversary to persistently inject a JavaScript payload into the administrator backend of a Magento store. When triggered, this JavaScript payload can then perform automated exploit steps in the browser of a victim. We visualize these steps in our video in form of our JavaScript-based RIPS shell.

When an employee of the store logs into the admin dashboard, the injected JavaScript payload runs and hijacks the administrative session of the employee. An authenticated Remote Code Execution vulnerability is then exploited, which results in a full takeover of the store by the attacker. The attacker could then cause financial harm to the company running the store. For example, the attacker could redirect all payments to his bank account or steal credit card information.

The vulnerabilities can be exploited if a Magento store uses the built-in, core Authorize.Net payment module, a Visa solution that allows for the processing of credit card payments. Please note that Authorize.Net is not responsible for any of the vulnerabilities, but rather the implementation in Magento. Since Authorize.Net is a popular payment processing service for credit cards, the exploit chain affects many Magento stores. Considering that testing if a target store uses the Authorize.Net module is easy and can be automated, mass exploitation is possible.

We rate the severity of the exploit chain as high, as an attacker can exploit it without any prior knowledge or access to a Magento store and no social engineering is required. Considering that all Magento stores transact over $155 billion annually, attackers are highly motivated to take advantage of such vulnerabilities.

Who is affected?

Affected are all Magento stores that have the Authorize.Net module enabled and run a vulnerable version, which are listed in the following table:

BranchPatched in versionVulnerable versions<= 2.3.1<= 2.2.8<= 2.1.17

Technical analysis

In the following we analyze two distinct security vulnerabilities that can be chained. Due to the severity of these issues, certain exploit details are omitted on purpose.

Unauthenticated Stored XSS

Magento provides multiple sanitization methods for different purposes. This section is going to detail a bypass for the escapeHtmlWithLinks() sanitization method and how a bypass lead to an unauthenticated Stored XSS vulnerability in the cancellation note of a new product order.

However, before discussing said method, it makes sense to first get some background knowledge on Magento sanitization and understand it’s main sanitization method, escapeHTML():


50   /**
51    * Escape string for HTML context.
52    *
53    * AllowedTags will not be escaped, except the following: script, img, embed,
54    * iframe, video, source, object, audio
55    *
56    * @param string|array $data
57    * @param array|null $allowedTags
58    * @return string|array
59    */
60   public function escapeHtml($data, $allowedTags = null)

All you have to know about escapeHTML() is that it parses user input ($data) and removes all HTML tags that are not specified with the second parameter, $allowedTags, from the user input string. If the second parameter is not set, the entire user input string will simply be escaped. The method furthermore allows only a few HTML attributes to bet set in each allowed tag, namely idclasshrefstyle and a few others.

We did not come up with a bypass for escapeHTML(), so we searched for code that acts on user input after it was sanitized with escapeHTML(), as modification of sanitized data often leads to vulnerabilities. We found the method escapeHtmlWithLinks(). The next paragraphs and snippets will explain how this method works and how a logic flaw in it lead to a XSS vulnerability.

The purpose of escapeHtmlWithLinks() is to remove all HTML tags except for a whitelisted set of tags from a user input string. The difference to escapeHTML() is that it will additionally remove all attributes except the href attribute from <a> tags within the user input string, in order to make links extra secure.

As the following code snippet shows, escapeHtmlWithLinks() starts off by parsing all <a> tags within the user input string into an array ($matches):


150    public function escapeHtmlWithLinks($data, $allowedTags = null)
151    {
152        ⋮
153        $data = str_replace('%', '%%', $data);
154        $regexp = "#(?J)<a"
155            ."(?:(?:\s+(?:(?:href\s*=\s*(['\"])(?<link>.*?)\\1\s*)|(?:\S+\s*=\s*(['\"])(.*?)\\3)\s*)*)|>)"
156            .">?(?:(?:(?<text>.*?)(?:<\/a\s*>?|(?=<\w))|(?<text>.*)))#si";
157        while (preg_match($regexp, $data, $matches)) {
158        ⋮

The next step is to sanitize the text of the link and the URL contained in the href attribute. This is done by recreating a minimalistic tag (line 164 - 169 in the next code snippet).

The resulting sanitized link is then stored in the $links array, which will be used later. The function escapeHtmlWithLinks() then replaces the original <a> tag, which was just sanitized, with a %$is within the user input string, where $i is simply the number of the replaced <a> tag.

 156    ⋮
 157    while (preg_match($regexp, $data, $matches)) {
 158    $text = '';
 159    if (!empty($matches['text'])) {
 160        $text = str_replace('%%', '%', $matches['text']);
 161    }
 162    $url = $this->filterUrl($matches['link'] ?? '');
 163    //Recreate a minimalistic secure a tag
 164    $links[] = sprintf(
 165        '<a href="%s">%s</a>',
 166        htmlspecialchars($url, ENT_QUOTES, 'UTF-8', false),
 167        $this->escaper->escapeHtml($text)
 168    );
 169    $data = str_replace($matches[0], '%' . $i . '$s', $data);
 170    ++$i;
 171    ⋮

To give a concrete example of what is described above and shown in the last code snippet, here is what would happen to an example user input at this stage of the sanitization method:

<i>Hello, <a href="/the-world/" title="Hello World">World!</a></i> would turn into <i>Hello, %1s</i>

After escapeHtmlWithLinks() has replaced all <a> tags with a corresponding %s in the user input string, it will pass the resulting user input to escapeHTML(). This will sanitize the user input securely (line 172 of the next snippet). However, it will then insert the sanitized links back into the now sanitized string via vsprintf(). This is where the XSS vulnerability occurs. We will discuss how exactly the XSS vulnerability works in the following paragraph.

 170    ⋮
 171    } // End of while
 172    $data = $this->escaper->escapeHtml($data, $allowedTags);
 173    return vsprintf($data, $links);

The issue with simply inserting the sanitized links into the escaped user input string is that escapeHtmlWithLinks() does not care about the position of an <a> tag within a string. The following table demonstrates how this can lead to a HTML attribute injection.

Step	User input string
Parse <a> tags from user input string	<i id=" <a href='http://onmouseover=alert(/XSS/)'>a link</a> "> a malicious link </i>
Replace <a> tags with a %s	<i id=" %1s "> a malicious link </i>
Remove all unwanted tags from user input string	<i id=" %1s "> a malicious link </i>
Insert sanitized <a> tags into sanitized string	<i id=" <a href="http://onmouseover=alert(/XSS/)>">a link</a> "> a malicious link </i>

StepUser input string
Parse <a> tags from user input string<i id=" <a href='http://onmouseover=alert(/XSS/)'>a link</a> "> a malicious link </i>
Replace <a> tags with a %s<i id=" %1s "> a malicious link </i>
Remove all unwanted tags from user input string<i id=" %1s "> a malicious link </i>
Insert sanitized <a> tags into sanitized string<i id=" <a href="http://onmouseover=alert(/XSS/)>">a link</a> "> a malicious link </i>

As can be seen in the above table, the <a> tag is replaced with a %1s and the user input string is then sanitized. As %1s is not a dangerous value, it passes the sanitization step. When escapeHtmlWithLinks() then reinserts the sanitized link with vsprintf(), an additonal double quote is injected into the <i> tag, which allows for an attribute injection.

This allows an attacker to inject arbitrary HTML attributes into the resulting string. By injecting a malicious onmouseover event handler and a style attribute to make the link an invisible overlay over the entire page, the XSS payload triggers as soon as a victim visits a page that contains such an XSS payload and moves his mouse.

The escapeHtmlWithLinks() method is used to sanitize order cancellation notes that are created when a user starts the order process with Authorize.Net but then cancels it. By abusing the bypass described above, an attacker can inject arbitrary JavaScript into the order overview of a just cancelled order. When an employee then reviews the cancelled order, the XSS payload triggers.

Authenticated Phar Deserialization

Once an attacker has hijacked the session of an authenticated user, he can abuse a Phar Deserialization vulnerability within the controller that is responsible for rendering images within the WYSIWYG editor. The following code snippet shows how the POST parameter __directiveis passed to the open() method of an image adapter class. This method internally passes the user input to the function getimagesize(), which is vulnerable for Phar deserialization.


53    public function execute()
54    {
55       $directive = $this->getRequest()->getParam('___directive');
56        $directive = $this->urlDecoder->decode($directive);
57        ⋮
58        $image = $this->_objectManager->get(\Magento\Framework\Image\AdapterFactory::class)->create();
59        try {
60            $image->open($imagePath);
61        ⋮

By injecting a phar:// stream wrapper into an image file handler, an attacker can trigger a PHP object injection. He can then chain POP gadgets from the Magento core that in the end lead to Remote Code Execution.


2018/09/25We report a Stored XSS vulnerability in Magento 2.2.6.
2018/11/28Magento releases a patch for the Stored XSS vulnerability in 2.2.7 and 2.1.16.
2018/12/13We report a bypass for the patch in Magento 2.3.0
2019/01/11We report the Phar Deserialization vulnerability to the Magento security team.
2019/01/26We discover that the Stored XSS can be triggered by unauthenticated attackers on Magento stores with a certain configuration. We inform Magento.
2019/01/29Magento verifies the vulnerability.
2019/03/26Magento releases a security update and fixes the Phar Deserialization in Magento 2.3.1, 2.2.8 and 2.1.17. The Stored XSS vulnerability is not mentioned in the changelogs and no patch is available.
2019/04/09Magento closes the ticket for the Stored XSS as "Resolved".
2019/04/09We ask Magento if this issue has been fixed, since no mention of it is in the changelogs and no modifications have been made to the escapeHTMLWithLinks() method.
2019/04/10Magento reopens the ticket.
2019/06/25A patch is made available in version 2.3.2, 2.2.9 and 2.1.18


This blog post detailed how an unauthenticated Stored XSS vulnerability can be combined with an authenticated Phar Deserialization vulnerability to hijack Magento stores on a mass exploitable scale. The technical sections demonstrated that the exploitation of today’s security flaws often depends on multiple sanitization, logic and configuration flaws. We highly recommend all users to update to the latest Magento version.
